13
13-58
32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN0 Message Slot 0 Standard ID1 (C0MSL0SID1)
<Address:
H
’0080 1101>CAN0 Message Slot 1 Standard ID1 (C0MSL1SID1)
<Address:
H
’0080 1111>CAN0 Message Slot 2 Standard ID1 (C0MSL2SID1)
<Address:
H
’0080 1121>CAN0 Message Slot 3 Standard ID1 (C0MSL3SID1)
<Address:
H
’0080 1131>CAN0 Message Slot 4 Standard ID1 (C0MSL4SID1)
<Address:
H
’0080 1141>CAN0 Message Slot 5 Standard ID1 (C0MSL5SID1)
<Address:
H
’0080 1151>CAN0 Message Slot 6 Standard ID1 (C0MSL6SID1)
<Address:
H
’0080 1161>CAN0 Message Slot 7 Standard ID1 (C0MSL7SID1)
<Address:
H
’0080 1171>CAN0 Message Slot 8 Standard ID1 (C0MSL8SID1)
<Address:
H
’0080 1181>CAN0 Message Slot 9 Standard ID1 (C0MSL9SID1)
<Address:
H
’0080 1191>CAN0 Message Slot 10 Standard ID1 (C0MSL10SID1)
<Address: H
’0080 11A1>CAN0 Message Slot 11 Standard ID1 (C0MSL11SID1)
<Address: H
’0080 11B1>CAN0 Message Slot 12 Standard ID1 (C0MSL12SID1)
<Address: H
’0080 11C1>CAN0 Message Slot 13 Standard ID1 (C0MSL13SID1)
<Address: H
’0080 11D1>CAN0 Message Slot 14 Standard ID1 (C0MSL14SID1)
<Address: H
’0080 11E1>CAN0 Message Slot 15 Standard ID1 (C0MSL15SID1)
<Address: H
’0080 11F1>CAN1 Message Slot 0 Standard ID1 (C1MSL0SID1)
<Address:
H
’0080 1501>CAN1 Message Slot 1 Standard ID1 (C1MSL1SID1)
<Address:
H
’0080 1511>CAN1 Message Slot 2 Standard ID1 (C1MSL2SID1)
<Address:
H
’0080 1521>CAN1 Message Slot 3 Standard ID1 (C1MSL3SID1)
<Address:
H
’0080 1531>CAN1 Message Slot 4 Standard ID1 (C1MSL4SID1)
<Address:
H
’0080 1541>CAN1 Message Slot 5 Standard ID1 (C1MSL5SID1)
<Address:
H
’0080 1551>CAN1 Message Slot 6 Standard ID1 (C1MSL6SID1)
<Address:
H
’0080 1561>CAN1 Message Slot 7 Standard ID1 (C1MSL7SID1)
<Address:
H
’0080 1571>CAN1 Message Slot 8 Standard ID1 (C1MSL8SID1)
<Address:
H
’0080 1581>CAN1 Message Slot 9 Standard ID1 (C1MSL9SID1)
<Address:
H
’0080 1591>CAN1 Message Slot 10 Standard ID1 (C1MSL10SID1)
<Address: H
’0080 15A1>CAN1 Message Slot 11 Standard ID1 (C1MSL11SID1)
<Address: H
’0080 15B1>CAN1 Message Slot 12 Standard ID1 (C1MSL12SID1)
<Address: H
’0080 15C1>CAN1 Message Slot 13 Standard ID1 (C1MSL13SID1)
<Address: H
’0080 15D1>CAN1 Message Slot 14 Standard ID1 (C1MSL14SID1)
<Address: H
’0080 15E1>CAN1 Message Slot 15 Standard ID1 (C1MSL15SID1)
<Address: H
’0080 15F1>9 10 11 12 13 14 b15b8
SID7SID6SID5 SID8 SID9 SID10
??????
<After reset: Undefined>
b Bit Name Function R W
8, 9 No function assigned. Fix to "0". 00
10–15 SID5–SID10 Standard ID5–standard ID10 R W
(Standard ID5–standard ID10)
These registers are the memory space for transmit and receive frames.
To Next Page
