ELECTRICAL CHARACTERISTICS
32180 Group User's Manual (Rev.1.0)
21.1 Absolute Maximum Ratings
Absolute Maximum Ratings
Symbol Parameter Test Condition Rated Value Unit
VCCE Main Power Supply VCCE=OSC-VCC -0.3–6.5 V
OSC-VCC Clock Power Supply VCCE=OSC-VCC -0.3–6.5 V
VCC-BUS Bus Power Supply VCCE=OSC-VCC -0.3–6.5 V
VDDE RAM Power Supply VCCE=OSC-VCC -0.3–6.5 V
AVCC Analog Power Supply VCCE≥AVCC≥VREF -0.3–6.5 V
VREF Reference Voltage Input VCCE≥AVCC≥VREF -0.3–6.5 V
VI Xin -0.3–OSC-VCC+0.3 V
VCNT -0.3–3.2 V
Other -0.3–VCCE+0.3 V
VO Xout -0.3–OSC-VCC+0.3 V
Other -0.3–VCCE+0.3 V
Pd Power Dissipation Ta=-40–85C° 600 mW
Ta=-40–125C° 500 mW
TOPR Operating Ambient Temperature (Note 1) -40–125 C°
Tstg Storage Temperature -65–150 C°
Note 1: This does not guarantee that the microcomputer can operate continuously at 125°C. Consult Mitsubishi if the
microcomputer is going to be used for 125°C applications.
