Renesas M32R/ECU Series User Manual

3
3-27
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (20/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1136 CAN0 Message Slot 3 Data 0 CAN0 Message Slot 3 Data 1 13-63
(C0MSL3DT0) (C0MSL3DT1) 13-64
H'0080 1138 CAN0 Message Slot 3 Data 2 CAN0 Message Slot 3 Data 3 13-65
(C0MSL3DT2) (C0MSL3DT3) 13-66
H'0080 113A CAN0 Message Slot 3 Data 4 CAN0 Message Slot 3 Data 5 13-67
(C0MSL3DT4) (C0MSL3DT5) 13-68
H'0080 113C CAN0 Message Slot 3 Data 6 CAN0 Message Slot 3 Data 7 13-69
(C0MSL3DT6) (C0MSL3DT7) 13-70
H'0080 113E CAN0 Message Slot 3 Timestamp 13-71
(C0MSL3TSP)
H'0080 1140 CAN0 Message Slot 4 Standard ID 0 CAN0 Message Slot 4 Standard ID 1 13-57
(C0MSL4SID0) (C0MSL4SID1) 13-58
H'0080 1142 CAN0 Message Slot 4 Extended ID 0 CAN0 Message Slot 4 Extended ID 1 13-59
(C0MSL4EID0) (C0MSL4EID1) 13-60
H'0080 1144 CAN0 Message Slot 4 Extended ID 2 CAN0 Message Slot 4 Data Length Register 13-61
(C0MSL4EID2) (C0MSL4DLC) 13-62
H'0080 1146 CAN0 Message Slot 4 Data 0 CAN0 Message Slot 4 Data 1 13-63
(C0MSL4DT0) (C0MSL4DT1) 13-64
H'0080 1148 CAN0 Message Slot 4 Data 2 CAN0 Message Slot 4 Data 3 13-65
(C0MSL4DT2) (C0MSL4DT3) 13-66
H'0080 114A CAN0 Message Slot 4 Data 4 CAN0 Message Slot 4 Data 5 13-67
(C0MSL4DT4) (C0MSL4DT5) 13-68
H'0080 114C CAN0 Message Slot 4 Data 6 CAN0 Message Slot 4 Data 7 13-69
(C0MSL4DT6) (C0MSL4DT7) 13-70
H'0080 114E CAN0 Message Slot 4 Timestamp 13-71
(C0MSL4TSP)
H'0080 1150 CAN0 Message Slot 5 Standard ID 0 CAN0 Message Slot 5 Standard ID 1 13-57
(C0MSL5SID0) (C0MSL5SID1) 13-58
H'0080 1152 CAN0 Message Slot 5 Extended ID 0 CAN0 Message Slot 5 Extended ID 1 13-59
(C0MSL5EID0) (C0MSL5EID1) 13-60
H'0080 1154 CAN0 Message Slot 5 Extended ID 2 CAN0 Message Slot 5 Data Length Register 13-61
(C0MSL5EID2) (C0MSL5DLC) 13-62
H'0080 1156 CAN0 Message Slot 5 Data 0 CAN0 Message Slot 5 Data 1 13-63
(C0MSL5DT0) (C0MSL5DT1) 13-64
H'0080 1158 CAN0 Message Slot 5 Data 2 CAN0 Message Slot 5 Data 3 13-65
(C0MSL5DT2) (C0MSL5DT3) 13-66
H'0080 115A CAN0 Message Slot 5 Data 4 CAN0 Message Slot 5 Data 5 13-67
(C0MSL5DT4) (C0MSL5DT5) 13-68
H'0080 115C CAN0 Message Slot 5 Data 6 CAN0 Message Slot 5 Data 7 13-69
(C0MSL5DT6) (C0MSL5DT7) 13-70
H'0080 115E CAN0 Message Slot 5 Timestamp 13-71
(C0MSL5TSP)
H'0080 1160 CAN0 Message Slot 6 Standard ID 0 CAN0 Message Slot 6 Standard ID 1 13-57
(C0MSL6SID0) (C0MSL6SID1) 13-58
H'0080 1162 CAN0 Message Slot 6 Extended ID 0 CAN0 Message Slot 6 Extended ID 1 13-59
(C0MSL6EID0) (C0MSL6EID1) 13-60
H'0080 1164 CAN0 Message Slot 6 Extended ID 2 CAN0 Message Slot 6 Data Length Register 13-61
(C0MSL6EID2) (C0MSL6DLC) 13-62
H'0080 1166 CAN0 Message Slot 6 Data 0 CAN0 Message Slot 6 Data 1 13-63
(C0MSL6DT0) (C0MSL6DT1) 13-64
H'0080 1168 CAN0 Message Slot 6 Data 2 CAN0 Message Slot 6 Data 3 13-65
(C0MSL6DT2) (C0MSL6DT3) 13-66
H'0080 116A CAN0 Message Slot 6 Data 4 CAN0 Message Slot 6 Data 5 13-67
(C0MSL6DT4) (C0MSL6DT5) 13-68
H'0080 116C CAN0 Message Slot 6 Data 6 CAN0 Message Slot 6 Data 7 13-69
(C0MSL6DT6) (C0MSL6DT7) 13-70
H'0080 116E CAN0 Message Slot 6 Timestamp 13-71
(C0MSL6TSP)
H'0080 1170 CAN0 Message Slot 7 Standard ID 0 CAN0 Message Slot 7 Standard ID 1 13-57
(C0MSL7SID0) (C0MSL7SID1) 13-58
H'0080 1172 CAN0 Message Slot 7 Extended ID 0 CAN0 Message Slot 7 Extended ID 1 13-59
(C0MSL7EID0) (C0MSL7EID1) 13-60
H'0080 1174 CAN0 Message Slot 7 Extended ID 2 CAN0 Message Slot 7 Data Length Register 13-61
(C0MSL7EID2) (C0MSL7DLC) 13-62
H'0080 1176 CAN0 Message Slot 7 Data 0 CAN0 Message Slot 7 Data 1 13-63
(C0MSL7DT0) (C0MSL7DT1) 13-64
H'0080 1178 CAN0 Message Slot 7 Data 2 CAN0 Message Slot 7 Data 3 13-65
(C0MSL7DT2) (C0MSL7DT3) 13-66
H'0080 117A CAN0 Message Slot 7 Data 4 CAN0 Message Slot 7 Data 5 13-67
(C0MSL7DT4) (C0MSL7DT5) 13-68
