Appendix 4
Appendix 4-30
32180 Group User's Manual (Rev. 1.0)
SUMMARY OF PRECAUTIONS
Figure 4.13.10 Example Processing of Pins Adjacent to the Oscillator and VCNT Pins
Adjacent pin/peripheral pin (set for input)
Method for limiting the effect of noise in input mode
Noise
Method for limiting noise with a resistor
Noise
Fast switching
Adjacent pin/peripheral pin (set for input)
Method for limiting the effect of noise in input mode
Adjacent pin/peripheral pin (set for output)
Method for limiting the effect of noise in output mode
Adjacent pin/peripheral pin (set for input)
Adjacent pin/peripheral pin (set for output)
Method for limiting switching noise with a resistor
Appendix 4.13 Precautions about Noise
