Workshop
Manual
Rolls- Royce Silver Shadow
&
Bentley
T
Series
Chapter
M
5.
Unscrew and remove the three screws retaining
3
Unscrew and remove the screws securing the
the switch to the console.
wooden
facia to the console, and slide the facia
6.
Rotate the switch through 9o0and withdraw
until it clears the retaining clip at
the base, then
from the rear of the console.
remove the
facia.
4.
Disconnect the electrical connections, noting
Hazard warning lamp
switch-To remove
1.
Disconnect the battery.
2.
Using a flat tool, carefully prise away from
the centre console the triangular trim pads situated
one each side of the centre console.
3.
Unscrew and remove the screws securing the
wooden
facia to the console and slide the facia
until it clears the retaining clip at the base; remove
the
facia.
-
the colours to facilitate fitting.
5.
Using a suitable tool remove the circular
switch securing nut; remove the switch
Rear interior lamps switch
-To remove
4.
Disconnect the electrical connections, noting
1.
Disconnect the battery.
the colours to facilitate fitting.
2.
Using a flat tool, carefully remove the vanity
5.
Unscrew anti-clockwise the switch knob, then
mirror and veneered surround.
remove the bulb.
3.
Separate the electrical connections, noting the
6.
Using a suitable tool, remove the circular
colours to facilitate fitting.
switch securing nut.
4.
Unscrew and remove the four screws securing
7.
Remove the switch.
the switch mounting plate to the rear of the mirror
veneered surround.
Rear window demister switch
-To remove
5.
Remove the hexagon headed nut securing the
switch to the switch mounting plate.
1.
Disconnect the battery.
Note
On cars from Car Serial Number 6000
2.
Using a flat tool carefully prise away from the
a circular securing nut is used as
centre console the two triangular trim pads
opposed to a hexagon headed nut.
situated one each side of the centre console.
6.
Remove the switch.
