Workshop Manual
Rolls Royce Silver
Shadow
b
Bentley
T
Series
Chapter
K
held downward to ensure that any slackness in the
carburetters slotted link (14) is removed. Fit the nut
and tighten the bolt.
9.
Remove the block of wood if one was used,
from the accelerator pedal.
10. Operate the mechanism and ensure that it func-
tions without fouling and that the fulcrum lever (5)
and control rod (3) do not tend to toggle over when
the accelerator pedal is released sharply from its full
throttle position. If the compensator mechanism does
toggle over, control rod (7) should be disengaged from
fulcrum lever (5) and control rod (3) lengthened until
toggling is prevented. Control rod
(7)
should then be
shortened to suit and re-fitted to fulcrum lever (5).
1 1. Tighten the lock-nuts.
12. Fit the kick-down button.
Kick-down button-To adjust
1. Slacken the large lock-nut, then adjust the
accelerate the car using light throttle, note the quality
of the gear changes on light throttle; these should take
place as follows.
(a) First to second gear-5
m.p.h. to 8 m.p.h.
(8 k.p.h. to 13 k.p.h.)
(b) Second to third gear-12 m.p.h. to 15 m.p.h.
(19 k.p.h. to 24 k.p.h.)
(c) Third to top gear-22 m.p.h. to 25 m.p.h.
(35 k.p.h. to 40 k.p.h.)
3. It should be noted that the gear changes will
occur at a higher road speed with a full throttle open-
ing. The gear changes should take place at the follow-
ing speeds.
(a) First to second gear-18
m.p.h. to 21 m.p.h.
(29 k.p.h. to 34 k.p.h.)
(b) Second to third gear-33 m.p.h. to 37 m.p.h.
(53 k.p.h. to 59 k.p.h.)
(c) Third to top gear-73 m.p.h. to 75 m.p.h.
(117 k.p.h. to 121 k.p.h.)
position of the kick-down button by screwing the body
up or down as required until the button is depressed
Final adjustment
a~~roximatel~
.ik
in. (1958 mm.) when the throttles are
If the changes are found to be 'slippy' and there is no
in the full throttle position. Tighten the lock-nut.
kick-down, advance the
T.V
lever by turning the
2.
If7 when adjusting the kick-down button, its
micro-adjuster anti-clockwise (viewed from the top).
position is such that it is in danger of being hidden by
1f the changes
are
jerky
or
late, the micro-adjuster
the carpet and thereby rendered ineffective, the
should be turned in the opposite direction.
accelerator to compensator link control rod should
be shortened. Shortening this rod will move the pedal
away from the toe board thus allowing the kick-down
button to be raised clear of the carpet; the accelerator
lever pedal-stop (if fitted) will have to be adjusted to
suit.
Torque Converter
Transmission
3. Ensure that the whole control mechanism oper-
ates smoothly, that the closed throttle condition is still
(All left-hand drive cars and late right-hand
available and that operation of the kick-down button
drive cars)
is noticeable.
4. The
kickdown setting quoted should provide
sufficient 'feel' for most owners, if however, a more
positive 'feel' is desired, the button may be raised a
small amount beyond the setting given.
Final
T.V.
adjustment
If
the controls have been set to the instructions already
given, the final setting should only involve adjustment
of the T.V. micro-adjuster and possibly the re-
setting of the kick-down button so that the 'feel' it
provides coincides with the advent of kick-down in the
gearbox.
Throttle control linkage settings
1. Loosely assemble the components onto the
engine.
2.
Set the levers on
'A'
bank control shaft (1) so
that the lever (2) is vertical when the manifold to
carburetter lever is connected to the carburetter control
link with all slackness in the carburetter coupling
twin-links taken up; refrigerated cars have links with
elongated holes in them. Tighten the lever pinch bolts.
Assembly of the pedal linkage to the
carburetter linkage
With the engine and transmission fitted into the car,
Car-TO road test
proceed to connect the pedal and compensator linkage
1.
Drive the car on the road to allow the engine
to the engine as follows.
and gearbox to reach normal working temperature
1.
Assemble the compensator linkage to the engine
then proceed as follows.
as shown in the appropriate illustration. (see Figs.
K34,
2.
Place the gear selector lever into position '4' and
K35
and
K36).
