Antennas
6.6 ANT D5
SIMATIC RF200
172 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Minimum distances from antenna to antenna
RF290R with ANT D5
RF290R with ANT D6
RF290R with ANT D10
RF290R with ANT D5
≥ 2 m
≥ 2 m
≥ 2 m
RF290R with ANT D6
≥ 2 m ≥ 2 m ≥ 2 m
RF290R with ANT D10
≥ 2 m
≥ 2 m
≥ 2 m
Definition of distance D
Figure 6-28 Distance D: ANT D5
