Siemens SIMATIC Ident System Manual

System overview
3.2 Overview of transponders
SIMATIC RF200
24 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Transponder
Area of application
MDS D400 Simple identification such as electronic barcode replacement/supplements, from warehouse and distribu-
tion logistics right through to product identification.
MDS D421 The MDS D421 is designed for tool coding according to DIN 69873.
It can be used wherever small data carriers and exact positioning are required, e.g. tool identification,
workpiece holders
MDS D422
Identification of metallic workpiece holders, workpieces or containers
MDS D423 Identification of metallic workpiece holders, workpieces or containers, production automation
MDS D424
Production and distribution logistics as well as in assembly and production lines
MDS D425 Compact and rugged ISO transponder; suitable for screw mounting.
Use in assembly and production lines in the powertrain sector; ideal for mounting on motors, gearboxes,
and workpiece holders
MDS D426 Compact and rugged ISO transponder; suitable for identification of transport units in production-related
logistics; can also be deployed in harsh conditions
MDS D428 Compact and rugged ISO transponder; suitable for screw mounting
Use in assembly and production lines in the powertrain sector
MDS D460
Assembly lines with very small workpiece holders
MDS D521 The MDS D521 is constructed for tool coding according to DIN 69873. It can be used wherever small data
carriers and exact positioning are required, e.g. tool identification, workpiece holders.
MDS D522
Identification of metallic workpiece holders, workpieces or containers
MDS D522
Special vari-
ants
If Identification of metallic workpiece holders or workpieces
MDS D524 Production and distribution logistics as well as in assembly and production lines
MDS D526 Compact and rugged ISO transponder; suitable for identification of transport units in production-related
logistics; can also be deployed in harsh environmental conditions
MDS D528 Compact and rugged ISO transponder; suitable for screw mounting
Use in assembly and production lines in the powertrain sector
1)
Only with the MLFB 6GT2600-0AA10
2)
Only with the MLFB 6GT2600-0AB10
Overview of the memory sizes of the ISO transponders for RF200
Transponder
Memory size
MDS D1xx
112 bytes of EEPROM
MDS D2xx
256 bytes of EEPROM
MDS D3xx
992 bytes of EEPROM
MDS D4xx
2000 bytes FRAM
MDS D5xx
8192 bytes FRAM
