Siemens SIMATIC Ident System Manual

Transponder
7.28 MDS D528
SIMATIC RF200
298 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6GT2600-5AK00
Mechanical specifications
Housing
• Material • Plastic PA 6.6 GF
• Color • Black
Recommended distance to metal
> 0 mm
Power supply
Inductive, without battery
Permitted ambient conditions
Ambient temperature
• During operation • -25 to +85 ℃
• During transportation and storage • -40 to +125 ℃
Degree of protection to EN 60529
• IP68
2 hours, 2 bar, +20 °C
• IPx9K
steam jet: 150 mm; 10 to 15 l/min; 100 bar; 75
°C
Shock-resistant to IEC 68-2-27
50 g
1)
Vibration-resistant to IEC 68-2-6
20 g
1)
Torsion and bending load
Not permitted
Design, dimensions and weight
Dimensions (Ø x H)
18 x 20 mm
Weight
35 g
Type of mounting 1 x transponder thread M8
≤ 8 Nm
1)
The values for shock and vibration are maximum values and must not be applied continuously.
