Appendix
A.2 Accessories
SIMATIC RF200
330 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6GT2690-0AH00
• MDS D139
• MDS D339
• Quick change holder for mounting on metal
• Distance from transponder to metal: 30 mm
• Mounting: Screw-in
• Material: Stainless steel VA
• Weight: 80 g
• Dimensions (Ø x H): 22 x 60 mm
6GT2690-0AH10
• MDS D139
• MDS D339
• Quick change holder for mounting on metal
• Distance from transponder to metal: 30 mm
• Mounting: Screw-in
• Material: Stainless steel VA
• Weight: 60 g
• Dimensions (Ø x H): 22 x 47 mm
6GT2690-0AK00
• MDS D124
• MDS D324
• MDS D424
• MDS D524
• Spacer for mounting on metal
• Distance from transponder to metal: 15 mm
• Mounting: 1 x M4 countersunk screw
• Tightening torque: ≤ 1 Nm
• Material: PPS
• Weight: Approx. 4 g
• Remounting cycles: at least 10
• Dimensions (Ø x H): 36 x 22 mm
6GT2690-0AL00
• MDS D126
• MDS D426
• MDS D526
• Spacer for mounting on metal
• Distance from transponder to metal: 25 mm
• Mounting: 1 x M4 countersunk screw
• Tightening torque: ≤ 1 Nm
• Material: PA6
• Weight: Approx. 12 g
• Remounting cycles: at least 10
• Dimensions (Ø x H): 59 x 30 mm
