RF200 system planning
4.2 Field data of transponders and readers
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
41
Length of the transmis-
sion window (L
d
)
Operating distance (S
a
)
Limit distance (S
g
)
MDS D424
37
0 ... 34
48
MDS D425
22 1 ... 12 20
MDS D426
65
0 ... 44
58
MDS D428
30
1 ... 20
32
MDS D460
24
1 ... 21
27
MDS D522
20
1 ... 12
15
MDS D522
Special variants
20 1 ... 12 15
MDS D524
35
1 ... 35
40
MDS D526
60
2 ... 35
45
MDS D528
25
1 ... 20
25
All dimensions in mm.
Table 4- 9 SIMATIC RF260R field data
Length of the transmis-
sion window (L)
Operating distance (S
a
)
Limit distance (S
g
)
MDS D100
120
2 ... 110
130
MDS D124
80
2 ... 80
85
MDS D126
110
2 ... 75
100
MDS D139
120
2 ... 80
110
MDS D160
60
2 ... 40
45
MDS D165
120
2 ... 120
135
MDS D200
120
2 ... 100
120
MDS D261
80
2 ... 75
90
MDS D324
80
2 ... 60
70
MDS D339
110 5 ... 65 80
MDS D400
140
2 ... 110
140
MDS D423
55 2 ... 40 45
MDS D424
80
2 ... 60
70
MDS D426
75
2 ... 70
85
MDS D428
50
2 ... 40
45
MDS D460
50
2 ... 40
45
MDS D524
70
2 ... 60
70
MDS D526
80
2 ... 70
85
MDS D528
50
2 ... 35
40
All dimensions in mm.
