RF200 system planning
4.2 Field data of transponders and readers
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
43
Table 4- 12 Field data SIMATIC RF290R, with ANT D10 (at 4 W)
Length of the transmission
window (L)
Operating distance (S
a
)
Limit distance (S
g
)
X direction
Y direction
MDS D100
1050
350
0 ... 500
600
MDS D124
1000
300
0 ... 200
280
MDS D126
1050 350 0 ... 400 500
MDS D139
1050
350
0 ... 450
550
MDS D160
1000
300
0 ... 130
180
MDS D165
1050
350
0 ... 350
450
MDS D200
1050
350
0 ... 450
550
MDS D261
1050
350
0 ... 350
450
MDS D324
1000
300
0 ... 200
280
MDS D339
1050
350
0 ... 300
380
MDS D400
1050
350
0 ... 400
500
MDS D424
1000
300
0 ... 200
280
MDS D426
1050
350
0 ... 350
400
MDS D524
1000
300
0 ... 220
300
MDS D526
1050
350
0 ... 350
400
All dimensions in mm.
