RF200 system planning
4.3 Installation guidelines
SIMATIC RF200
64 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Transponder
RF250R with ANT 30
antenna without met-
al
antenna flush-
mounted in metal
(all round 20 mm)
MDS D160
1)
without metal
100
85
on metal, distance 10 mm
95
80
MDS D324
1)
without metal 100 80
on metal, distance 15 mm
95
75
flush-mounted in metal;
distance all round 25 mm
85 70
MDS D422
without metal
100
95
flush-mounted in metal;
distance all round 0 mm
95 80
MDS D423
without metal
100
90
on metal, distance 0 mm
130
2)
110
2)
flush-mounted in metal;
distance all round 10 mm
80 70
MDS D424
1)
without metal
100
85
on metal, distance 15 mm
90
75
flush-mounted in metal;
distance all round 25 mm
75 70
MDS D425
without metal
100
90
on metal, distance 0 mm
95
75
MDS D426
1)
without metal
100
70
on metal, distance 25 mm
90
65
flush-mounted in metal;
distance all round 25 mm
55 45
MDS D428
without metal
100
90
on metal, distance 0 mm 100 90
MDS D460
1)
without metal
100
85
on metal, distance 10 mm
90
75
MDS D522
without metal
100
95
flush-mounted in metal;
distance all round 0 mm
95 80
MDS D522
Special variant
without metal
100
95
flush-mounted in metal;
distance all round 0 mm
95 80
MDS D524
1)
without metal
100
85
on metal, distance 15 mm
90
75
flush-mounted in metal;
distance all round 25 mm
75 70
MDS D526
1)
without metal
100
70
on metal, distance 25 mm
90
65
flush-mounted in metal;
distance all round 25 mm
55 45
