PRISM HEIGHT IS UNKNOWN:
OPERATIONAL STEPS
OPERATION
DISPLAY
①First finish settings of job, station
and orientation, and press [F4] to start
Remote Height measurement.
[F4]
【Remote Height】
[ * ] F1 Setting Job (1)
[ * ] F2 Setting Station (2)
[ * ] F3 Set Orientation (3)
F4 Start (4)
②Press [F4](↓) under the screen of
Remote Height measurement menu to
turn to next key page.
[F4]
【Base Point】
Sight Meas Base Pt！
Pt ： 10
R.HT： 1.500 m
： ---.--- m Ⅰ
All DIST RECORD ↓
R.HT EDM ∣←
③ Press [F1] (R.Ht) to enter into
remote-height measurement mode of
unknown prism height .
[F1]
【Base Point】
Sight Meas Base Pt！
Pt ： 10
： ---.--- m Ⅰ
BACK EDM |←
④Press [F4](|←) to return to previous
page key. Input PtID of base point, and
collimate prism center, by pressing
[F1] (All) or [F2] (DIST) + [F3]
(RECORD) to start measurement.
[F4]
Input base
PtID
+
[F1]
【Base Point】
Sight Meas Base Pt！
Base Point： 10
： ---.--- m Ⅰ
BACK EDM ∣←
All DIST RECORD ↓
⑤Screen displays horizontal distance
between instrument and prisms.
[F1](BACK): Input and measure a new
base point.
【Base Point】
Sight Meas Base Pt！
BasePt： 10
R.HT ： 0.000 m
： 1.968 m
V： 92°05′52″ Ⅰ
BACK V-ANG
