STONEX R2
Horizontal alignment consists of the following elements: start point, line, curve and spiral.
To define a horizontal alignment, user should first input the detailed information (Chain,
N, E coordinate) of start poin.
Serial number and the amount of present horizontal alignment are displayed on the upper
right corner of the screen.
The element of start point consists of the start chainage and E, N coordinate of start point.
Enter these details, and press [F2] (NEXT) to display the main inputting approach.
The screen displays: current chainage, the azimuth angle of the tangent on the chainage,
and the function key of the establishing new line. The system provides four functions:
defining line, curve, spiral, and point.
Select a function key, enter the detailed information of the chainage, the alignment
elements will be created. Press [F2] (BACK) to calculate the new chainage and azimuth
angle automatically and return to the alignment main menu. Now other line type can be
defined. Press [ESC] to quit the present screen and return to the screen of alignment
element. Modification on the element entered previously is available.
① In Road menu, press [F4] to enter
into Road function. As the method to
set job, station and orientation have
been introduced, they are not to be
introduced here.
【Roads】
[ * ] F1 Setting Job (1)
[ * ] F2 Setting Station (2)
[ * ] F3 Set Orientation (3)
F4 Start (4)
【Define HZ AL】 1/1
Type： POINT
Chain.： 100.000 m
X/N ： 100.000 m
Y/E ： 50.000 m
PREV NEXT SEARCH ↓
【HZ Alignment Type】
Chain.： 100.000 m
AZ： 0°00′00″
LINE ARC SPIRAL POINT
