②Press [F1] to enter into Define HZ
Alignment function.
[F1]
【Roads】
F1 Define HZ Alignment
F2 Define VT Alignment
F3 Stake Out Roads
③ Input the coordinate of start
chainage. After finishing one item,
press [ENT] to move to the next item.
Input start
chainage, and
N, E
coordinate
+
[ENT]
【Define HZ AL 】 1/0
Type： Start Pt
Chain. ： ---.--- m
X/N ： ---.--- m
Y/E ： ---.--- m
PREV NEXT SEARCH ↓
④ when all items have been
input, press [F2] (NEXT) to store start
point information. The program
displays: “Save Edit Alignment?” If
yes, press [F4] (OK). To re-edit it,
press [F1] (CANCEL).
[F2]
【Define HZ AL】
Save Edit Alignment?
CANCEL OK
⑤ Enter into Horizontal Alignment
main menu.
【HZ Alignment Type】
Chain.： 100.000 m
AZ： 0°00′00″
LINE ARC SPIRAL
Line
When the start point or other line type is defined, user can define line. A line consists of
azimuth angle and distance. The distance value can not be negative.
OPERATIONAL STEPS
OPERATION
DISPLAY
①Press [F1] (LINE) to enter into HZ
Alignment Type menu.
[F1]
【HZ Alignment Type】
Chain.： 100.000 m
AZ ： 0°00′00″
LINE ARC SPIRAL POINT
