OPERATIONAL STEPS
OPERATION
DISPLAY
① In File Management menu, press
[F3] to enter into point measurement
function.
[F3]
【File Management 】 1/2
▼
F1 Job (1)
F2 known points (2)
F3 Measurements (3)
F4 Code (4)
F1 F2 F3 F4
②The system takes the current job
name as the default job to view. To
examine the other measurement data,
input the job name and press [ENT]
to move to station point item.
[ENT]
View Measurement
Job： 2222
Stn.Pt： *
PtID: *
F4 View All Meas.Value
LIST VIEW
③The examination scope defaulted in
this system is all measurement stations
in the job to be examined (“*” ), as the
right graph shows. Therefore, to view
all measurement data in job, just press
[F4] (VIEW).
【View Measurement】
Job： 2222
Stn.Pt： *
PtID: *
F4 View All Meas.Value
LIST VIEW
④ The screen displays various
measurement information starting
with the first data in job. “1” on the
upper right corner of screen represents
that this point is the first data in job.
‴1)～‴3)
View 1
Type： Para.Sys.ness
Date： 2011.06.21
Time： 14:44:12
START LAST FIND
