STONEX R2
160
⑤
A:
Press [PAGE] to display other pages of
this data.
B:
Press to display all data in the job
one by one.
A:Find the other page:
B:Find the other data
EDM Type: IR
EDM Mode: Fine[S]
Prism type: Prism
Prism: -30mm
START LAST FIND
【View】 2
Type : Station SYS.MESS
StnPt : OCC1
INS.Ht : 1.000 m
Date : 2010.08.22
Time : 14:44:52
FIND
⑥ Press [F4] (FIND) to return to
View Measurements main menu.
To return to File Management menu,
press [ESC].
【View Measurements】
Job: 2222
Stn.Pt: *
PtID: *
F4 View All Meas.Value
LIST VIEW
‴1) The first data of general job documents displays some measurement information, such as: Data of
job establishment, type of prism, EDM, etc.
‴2) indicates that user can use navigation key to display each data in job.
‴3) ▼, ,▲indicates that there are still some other pages of this data, and it may be displayed by
pressing [PAGE].
6.3.1.2 Viewing Designated PtID in Job
Starts searching point. R2 Total Station provides point search function based on taking
measurement station as searching condition. Determine the searching scope at first: it
may be one PtID of one station in job;Or all measurement data named with this PtID
(“*”) in job. Therefore, in operation, user can input complete pointIDs or the pointIDs
with wildcard “*”.
OPERATIONAL STEPS
OPERATION
DISPLAY
①In View Measurements menu, input
the job name to search, or
Press[F1](LIST) to call the job from
internal memory. Then press [ENT] to
move to the next inputting area.
【View Measurements】
Job: 2222
Stn.Pt: *
PtID: *
F4 View All Meas.Value
LIST VIEW
