STONEX R2 User Manual

STONEX R2
28
S
………………………….
Oblique Distance
NOTE: The atmosphere refraction modulus of this instrument has been set as: K=0.14. It
also can be set shut: (0 VALUE)
OPERATIONAL STEPS
OPERATION
DISPLAY
①In EDM Settings screen, press [F1]
(Atmos) to enter atmospheric
correction function.
[F1]
【EDM Settings】
EDM Mode： Tracking
Reflect: Prism
Prism： 30.0mm
ATMOS GRID SET ↓
②The current settings displays on the
screen.
【Atmosphere Data】
Retr..Corr： 0.14
Temp： 20‵
Pressure： 1013.2 hPa
Atmos PPM： 0 PPM
BACK PPM=0 SET
③Input refraction modulus. E.g.: input
0.2, and press [ENT], moving the
cursor to Temp item. ‴1)，‴2)
Input 0.20
+
[ENT]
【Atmosphere Data】
RetrCorr： 0.20
Temp ： 20‵
Pressure ： 1013.2 hPa
Atmos PPM： 0 PPM
BACK PPM=0 SET
④As the settings are finished, press
[F4] to store and return to the previous
menu, here you have to press
[F3](SET) to save settings and return
to measure function.
[F4]
[F3]
【EDM Settings】
EDM Mode： Tracking
Reflect: Prism
Prism： -30.0mm
ATMOS GRID SET ↓
‴1)The inputting scope of refraction modulus: 0.00(SHUT) ～0.20
‴2) please refer to “2.7 INPUTING MODE” for inputting instruction.
Atmospheric Parameters (ppm):
Distance measurement is influenced directly by the atmospheric conditions of the air in
which distance measurement are taken.
In order to take into consideration these influences distance measurements are corrected
by using atmospheric correction parameters.
Temperature: Air temperature at instrument location.
Pressure: Air pressure at instrument location.
Atmos PPM: Calculated and indicated atmospheric PPM.
