STONEX R2 User Manual

STONEX R2
55
⑥When the screen displays the height
of known point, press [F1](All) or
[F2](DIST) + [F3](RECORD) to start
measuring. The height of station can be
calculated.
[F1]
Or
[F2]
+
[F3]
【Height Transfer】 1
Select Target Meas!
Pt ID： 1
R. HT： 1.500 m
H / Z ： 0.0000 m
： ---.--- m Ⅰ
All DIST SEARCH ↓
⑦ Press PAGE to turn to Page 2 to
display the measurement result.
PAGE
【Height Transfer】 1/2
HT. Tran. Result
Stn. Pt. :
Corr. : 1.500 m
No. Pts ： 10.0000 m
Add Pt FACE BACK OK
【Height Transfer】 2/2
HT. Tran. Result OCC1
Stn. Pt. :
X0/N0 : 1.500 m
Y0/E0 ： 10.0000 m
H0 : 8.250 m
No. Pts ： 10.0000 m
St. Dev.:
Add Pt FACE BACK OK
⑧Press [F2] (FACE) to measure the
same target in second face.
If you don‟t need to face measure
the same point, press [F1] (Add Pt) to
add a measurement of the known
point.
[F2]
【Height Transfer】
Turn to face！
【Height Transfer】 1
Select Target Meas!
Pt ID： 1
R. HT： 1.500 m
H / Z ： 10.0000 m
： ---.--- m Ⅰ
All DIST SEARCH ↓
