⑤Select the known point and input the
reflector height.
The amount of known points is
shown on the upper-left corner of the
screen.
There are 3 ways to select known
points.
A：Press [LIST], and press navigation
key to call up the needed point from
the job. Press [ENT] to return to the
screen of Height Transfer
measurement.
B：Input the known point ID and press
[SEARCH] to search whether there is
such a point ID in the job. Be there
some points with the same ID, press
to select the point needed.
Press [ENT] to return to the screen of
Height Transfer measurement.
C：You may also input a point ID
which does not exist, and press [ENH].
Then input the height of the point, save
the data and return to the screen of
Height Transfer measurement.
[F1]
Input known
point, prism
height
A：Press [LIST]：
B：Input point ID to the known point, press
[SEARCH]
C：Input the ID which does not exist, and press
[ENH]
【Height Transfer】 1
Select Target Meas!
Pt ID： --- ---
R. HT： 1.500 m
H / Z ： ---.--- m
： ---.--- m Ⅰ
All EDM SEARCH ↓
LIST DIST RECORD ↓
EHN INS.HT VIEW |←
【Pt. Search 】 1/254
1 Known
2 Known
3 Known
4 Known
5 Known
6 Known
VIEW EHN JOB ↓
【Height Transfer】 1
Select Target Meas!
Pt ID： 1
R. HT： 1.500 m
H / Z ： ---.--- m
： ---.--- m Ⅰ
All EDM SEARCH ↓
【Height Transfer】 1
Select Target Meas!
Pt ID： 1
R. HT： 1.500 m
H / Z ： ---.--- m
： ---.--- m Ⅰ
All DIST SEARCH ↓
【Height Transfer】
PtID： SA
H ： ---.--- m
BACK SAVE
