STONEX R2 User Manual

STONEX R2
93
⑤ Input the standard deviation. After
inputting one item, and press [ENT].
After inputting all deviations, press
[F4] (SET), and the screen displays
“Limit set already!” and returns to Free
Station menu.
Input standard
deviations
+
[F4]
Setting Limit
Input Limit!
Status: ON
St. dev. X/N ： 0.020 m
St. dev. Y/E： 0.020 m
St. dev. H/Z ： 0.010 m
St. dev. Ang： 0°00′00″
SET
⑥ Press [F4] to start free station
measurement. Set PtID and height of
the station. After one setting, press
[ENT]. After finishing inputting all
items, press [F4] (OK).
[F4]
Input station
PtID and
height
+ [ENT]
【Free Station STN Pt】
Stn.Pt: OCC1
INS. Ht: 1.500 m
O k
⑦ Set target PtID and prism height.
After inputting, press [F3] (OK). ‴1)
Input target
PtID and
R.HT
+
[F3]
【Free-Station TGT Pt 】
PtID ： 2
R.HT ： 2.000 m
SEARCH LIST OK ↓
⑧ Collimate target point 1 and press
[F3](DIST) to start measurement.
[F3]
【Free-Station Measure】
PtID ： 2
R.HT ： 2.000 m
HZ: 38°20′06″
V : 20°00′05″
: ---.--- m Ⅰ
RESULT Next Pt All ↓
⑨After finishing the measurement of
one point, press [F2] to proceed the
measurement of next point and repeat
steps ⑦, ⑧. If the measured point is
to be remeasured, press [F2] (SKIP) in
Page 2 without inputting PtID.
[F2]
【Free-Station TGT Pt】
PtID ： 2
R.HT ： ---.--- m
SEARCH LIST OK ↓
ENH SKIP BACK ∣←
