2
INSIGHT Software
Operation
28 Evolution 200 Series User Guide Thermo Scientific
Quant
Formulas and Units Tab
Quantifying Samples Using Standards
Y To quantify samples using standards
1. Click Measure Quant in Quant.
2. If standards need to be acquired, click Measure. If standards have already been acquired,
skip to step 7 to acquire sample data.
3. Follow the instructions that appear.
4. When standards information appears, modify it if desired.
More:
If Standard averaging on the Standards tab in Settings was set to Duplicate, “D” at the
end of a standard name indicates the second measurement to be made of the standard. If
Sample averaging was set to Triplicate, “D” and “T” at the end of standard names indicate
the second and third measurements to be made, respectively.
To enter previously saved standards information, use Import Standards.
If Calculate from weight/volume was selected on the Standards tab, enter the weight and
volume for each standard in the table.
To remove a standard, select it, right-click the table and choose Clear Standard. To
remove all the standards, choose Clear Table.
To save standards information for later use, use Export Standards.
5. Click Continue.
6. Follow the instructions that appear, installing the specified standards.
Note Select Measure single standard, Standard curve, Standard curve with two
wavelengths or Advanced standard curve on the Type tab before using this procedure.
Note To start an analysis immediately after viewing or changing the template settings,
start with the next step.
