INSIGHT Software
Operation
Thermo Scientific Evolution 200 Series User Guide 37
Y To view the X and Y values of a point
1. Select the spectral cursor tool.
2. Click the data display.
Cross hairs appear. The X and Y coordinates of their intersection with the spectrum
appear below the palette.
To move the cross hairs, drag across the pane or use the left and right arrow keys on the
keyboard.
To remove the cross hairs from the display, select another tool such as the selection tool.
Related Topics
Using the Selection Tool
Using the Peak/Valley Measurement Tool
Using the Peak Area Tool
Using the Region-Threshold Tool
Using the View Finder
Using the Peak/Valley Measurement Tool
Use the peak/valley measurement tool (if present) to measure the height of a peak or depth of
a valley from a specified baseline.
Y To measure a peak or valley
1. Select the peak/valley measurement tool.
2. Click the data display.
A vertical line appears. The X and Y coordinates of its intersection with the spectrum
appear below the palette.
3. Drag the line by its diamond-shaped handle to the peak or valley to measure.
4. Drag the triangular baseline handles to the desired baseline endpoints.
The height or depth of the peak or valley appears below the palette.
Note To display the palette, click .
Note To display the palette, click .
