ENGINE
4-69TX525 Service Manual Rev. 000
24. Capallthehydrauliclinesandttingssothatdebris
doesnotenterthesystem.
25. Removethebreatherfromthehydraulicoilbreather
hose(Fig.0332).
23. Slidethehosesoffthesuctionttings(Fig.0331).
Fig 0332 PICT-4946a
Fig 0331 PICT-4775a
26. Removethe4boltssecuringthegrillassemblyto
theframe(Fig.0333).
Fig 0333 PICT-4953
27. Slidethegrillassemblyforward(Fig.0334).
Fig 0334 PICT-4955
