ENGINE
4-70 Rev. 000 TX525 Service Manual
28. Removethe2boltsandnutssecuringtheoverow
tankbrackettothegrillassembly(Fig.0335).
Fig 0335 PICT-4959
29. Removethegrillassemblytakingcarenottodam-
agethehydraulictankbreatherhose(Fig.0336).
Fig 0336 PICT-4961
30. Inspectthefoamsealsontheinsideofthegrillas-
sembly.Replaceifwornordamaged(Fig.0337).
Fig 0337 PICT-5138a
31. Placeanabsorbenttowelundertheoilcoolerinlet
linettinglocatedonthelowerlefthandcornerof
the oil cooler.
32. Using1-1/16”and1-1/8”wrenches,removethe
hydraulicoilinletlinefromtheoilcoolerinlettting
(Fig.0338).
Fig 0338 PICT-4965
