ENGINE
4-84 Rev. 000 TX525 Service Manual
87. Positionthecableguideandtheroutedharness
cablesawayfromtheengineassembly(Fig.0390).
Fig 0390 PICT-5480
88. Usinga9/16”socketandwrench,removethe
remaining2boltsandnutssecuringtherighthand
sideoftheengineassemblymounttothemainframe
(Fig.0391).
Fig 0391 PICT-5481
89. Usinga9/16”socketandwrench,removethebolt
andnutsecuringthelefthandsideoftheengine
assemblymountandcableguidetothemainframe
(Fig.0392).
Fig 0392 PICT-5482
90. Positionthecableguideandtheroutedharness
cablesawayfromtheengineassembly(Fig.0393).
Fig 0393 PICT-5483
