ENGINE
4-101TX525 Service Manual Rev. 000
19. Torquethe2boltsto30+3ft-lbs.(40.6+5.4Nm)
(Fig.0458).
Fig 0458 IMG_8095
20. Withthesealingo-ringinplace,inserttheengine
shutdownsolenoidintotheengine(Fig.0459).
Fig 0459 PICT-5534
Note: Install the solenoid rod into the guide hole of
the cylinder block (Fig. 0460).
Fig 0460 IMG_8097a
21. Usinga5mmAllenwrench,install2boltsandlock
washerssecuringtheengineshutdownsolenoidto
theengine(Fig.0461).
Fig 0461 PICT-5532
