ENGINE
4-102 Rev. 000 TX525 Service Manual
22. Routethesolenoidwireandpositiontheengine
shutdownsolenoidbracketontotheengineblock
(Fig.0462).
Fig 0462 IMG_8098
23. Usinga10mmsocket,install2boltssecuringthe
engineshutdownsolenoidbrackettotheengine
(Fig.0463).
Fig 0463 PICT-5531
26. TX525(22319and22320#280000001andhigher)
hasastraighttting(Fig.0465):
Fig 0465 PICT-8773a
24. Oildraintting:Thereare2oildrainttings.
25. TX525(22319and22320#270000001through
270999999)hasa90degreetting(Fig.0464):
Fig 0464 PICT-5550
