ENGINE
4-115TX525 Service Manual Rev. 000
19. Positiontherighthandcableguideandtherouted
harnesscablesaligningthecableguidemounting
holewiththeengineandmainframemountinghole
(Fig.0512).
Fig 0512 PICT-5578
20. Usinga9/16”socketandwrench,looselyinstall
aboltandnutsecuringtherighthandsideofthe
engineassemblyandcableguidetothemainframe
(Fig.0513).
Fig 0513 PICT-5479
21. Torqueall6enginemountingboltsto30+3ft-lbs.
(41+4Nm)(Fig.0514).
Fig 0514 PICT-5579
22. Slidetheoildrainhoseontotheoildraintting
locatedonthebottomoftheoilpan.Positionthe
hoseclampandtightensecuringtheoildrainhose
totheengine(Fig.0515).
Fig 0515 PICT-5477
