ENGINE
4-124 Rev. 000 TX525 Service Manual
52. Watertemperatureharnesswirerouting:
 TX525(#270000001-270000400):uptheleftside
oftheengine,betweentheengineblockandalter-
nator,uptothetemperaturesensor(Fig.0547).
Fig 0547 PICT-5596
 TX525(#270000401&higher):upbetweenthedip-
stickandalternator(Fig.0548).
Fig 0548 PICT-5599a
53. Plugtheharnessterminalintothewatertemperature
sensor(Fig.0549).
Fig 0549 PICT-5429
54. Routethedrivebeltaroundthepulleys(rearview)
(Fig.0550).
Fig 0550 TX525beltrouting
A. LeftHandPumpPulley D. IdlerPulley
B. DriveBelt E. EnginePulley
C. RightHandPumpPulley
A
C
D
E
B
