ENGINE
4-125TX525 Service Manual Rev. 000
55. Usingaspringtool(Torop/n:92-5771),hookthe
idlerspringtothespringpostonthetower(Fig.
0551).
Fig 0551 PICT-5601
56. Positiontheheatshield(Fig.0552).
Fig 0552 PICT-5421
57. Usinga3/16”Allenwrench,installthetop2screws.
Usinga1/2”socket,installthebottom2screws
securingtheheatshieldtothetower(Fig.0553).
Fig 0553 PICT-5419a
58. Installthehoodrod(Fig.0554).
Fig 0554 PICT-5418
