67. Slidetheintakehoseontotheengineintake(Fig.
0563).
Fig 0563 PICT-5407
Fig 0565 PICT-5408
Fig 0564 PICT-5405
68. Positionthehoseclamp.Usinga3/8”socket,tighten
thehoseclampsecuringtheintakehosetothe
engineintake(Fig.0564).
69. Usinga1/2”socket,looselyinstall2boltssecuring
theaircleanerassemblytothemufershield(Fig.
0565).
Fig 0566 PICT-5412
70. Usinga13mmsocket,looselyinstall2newboltsand
washerssecuringtheaircleanermountingbracket
totheengineblock(Fig.0566).
