ENGINE
4-129TX525 Service Manual Rev. 000
Fig 0567 PICT-5408
71. Tightenthe2boltssecuringtheaircleanerassembly
tothemufershieldandthe2boltsandwashers
securingtheaircleanermountingbrackettothe
engineblock(Fig.0567).
72. Carefullyplacetheradiatorandoilcoolerassembly
intotheframe(Fig.0568).
Fig 0568 PICT-5402
73. Usinga1-1/16”anda1-1/8”wrench,installthe
hydraulicoiloutletlinetotheoilcooleroutlettting
(Fig.0569).
Fig 0569 PICT-4968a
74. Usinga1-1/16”anda1-1/8”wrench,installthe
hydraulicoilinletlinetotheoilcoolerinlettting(Fig.
0570).
Fig 0570 PICT-4965
