Toro TX525 - Page 183

ENGINE
4-130 Rev. 000 TX525 Service Manual
75. Slidetheradiatorhoseontotheengineblockoutlet
(Fig.0571).
Fig 0571 PICT-5400
76. Positionthehoseclamp.Usinga3/8”socket,tighten
thehoseclampsecuringtheradiatorhosetothe
engineblock(Fig.0572).
Fig 0572 PICT-5399
77. Slidethe2radiatorhosesontotheradiatorlltube
andthethermostathousing(Fig.0573).
Fig 0573 PICT-5397
78. Positionthe2hoseclamps.Usinga3/8”socket,
tightenthehoseclampssecuringtheradiatorhoses
totheradiatorlltubeandthermostathousing(Fig.
0574).
Fig 0574 PICT-5395
