Toro TX525 - Page 184

ENGINE
4-131TX525 Service Manual Rev. 000
79. Positiontheradiatormountintotheframe(Fig.
0575).
Fig 0575 PICT-4971
80. Usinga1/2”socket,looselyinstall3screwsholding
theradiatormounttotheframe(Fig.0576).
Fig 0576 PICT-5131
81. Centertheradiatorandoilcoolerassemblysideto
sideintheframesothatthereisapproximately1/8”
(3.2mm)gapbetweentheshroudandthefan.Spin
thecoolingfan.Ensurethefandoesnotcomeinto
contactwiththeshroud.Adjusttheradiatorsideto
sideasnecessary(Fig.0577).
Fig 0577 PICT-5135
82. Withoutmovingthepositionoftheradiator,slidethe
radiatormountagainsttheradiatorandtightenthe3
radiatormountscrews(Fig.0578).
Fig 0578 PICT-5137
