Toro TX525 - Page 185

ENGINE
4-132 Rev. 000 TX525 Service Manual
84. Positionthegrillontotheframeandroutethe
breathertubeinbetweenthefoamsealsontheinner
leftsideofthegrill(Fig.0580).
Fig 0580 PICT-5139
83. Inspectthefoamsealsontheinsideofthegrillas-
sembly.Replaceifwornordamaged(Fig.0579).
Fig 0579 PICT-5138
85. Slidethegrillontotheframesoitsitsunderthe
loaderstopsandontopoftheradiator.Leavethe
grillinaslightlyforwardposition.Theoverowtank
mountingholesshouldbejustbeyondtherighthand
bossontopoftheradiatorassembly.Thiswillallow
theoverowbottleassemblytobeinstalled(Fig.
0581).
Fig 0581 PICT-5141a
86. Positiontheoverowtankbracketontothegrill
assembly(Fig.0582).
Fig 0582 PICT-5143a
