ENGINE
4-134 Rev. 000 TX525 Service Manual
90. Checkthecoolingfanandshroudclearance.Adjust
thepositionoftheradiatorifnecessary.
91. Usinga9/16”socket,installthe2boltsandwashers
(ifpresent)securingtheradiatortothegrillassembly
(Fig.0588).
Fig 0588 PICT-5604
89. Usinga1/2”socket,tightenthe4boltssecuringthe
grillassemblytotheframe(Fig.0587).
Fig 0587 PICT-5150
92. Positionthebreathertubeunderthegrillandinstall
thebreather(Fig.0589).
Fig 0589 PICT-5157
93. Installtheleftandrighthandsidepanels(Fig.0590).
Fig 0590 PICT-4945
