ENGINE
4-136 Rev. 000 TX525 Service Manual
98. Usinga1/4”hexwrench,installtheengineoildrain
pluglocatedontheundersideoftheframeinsidethe
righthandwheelandtrackassembly(Fig.0595).
Fig 0595 PICT-3283
99. Slidethebatterypartiallyintothebatterymount.
Installthepositivebatterycabletothepositive
batteryterminal.Slidethebatteryfartherintothe
batterymount.Installthenegativebatterycableto
thenegativebatteryterminal.Slidethebatteryguard
inbetweenthebatteryandtheframesothatthehole
intheguardlinesupwiththebatteryclampmounting
holeintheframe(Fig.0596).
Fig 0596 PICT-4330
100. Positionthebatteryclampintotheslotonthe
batterymountandlineupthemountingholewith
theholeintheframe.Installabolt,washerand
nuttosecurethebatteryclamptotheframe(Fig.
0597).
Fig 0597 PICT-4310a
101. Slidethe2fuellinesontothefueltankttings.
Notethelocationmarkings(Fig.0598).
 S-Fuelsuctionline
 R-Fuelreturnline
Fig 0598 PICT-4265
