ENGINE
4-150 Rev. 000 TX525 Service Manual
Note: To adjust the amount of wire going through
the swivel loosen the two adjusting nuts
securing the cable to the throttle bracket. To
shorten the cable, thread the nuts toward the
cable end. To lengthen the cable, thread the
nuts further onto the cable (Fig. 0648).
Fig 0648 PICT-7113
9. Thereshouldbeapproximately3/16”to1/4”(0.48to
0.635cm)ofwirethroughtheswivel(Fig.0647).
Fig 0647 PICT-7107
10. Usingtwo7/16”wrenches,tightenthetwoadjusting
nutssecuringthethrottlecabletothethrottleplate
(Fig.0649).
Fig 0649 PICT-7143a
11. Holdthethrottleleverovertothelowidlestop.
Usinga1/4”wrench,tightentheswivelclampscrew
toholdthethrottlecablewire(Fig.0650).
Fig 0650 PICT-7111
