ENGINE
4-174 Rev. 000 TX525 Service Manual
12. Slidetheyokeassemblyoffofthearmature(Fig.
0736).
14. Removetheplatefromthestarter(Fig.0738).
Fig 0736 PICT-8042a
Fig 0738 PICT-8044a
15. Removethe3gearsfromontopofthestartershaft
assembly(Fig.0739).
13. Removethearmatureassembly(Fig.0737).
Fig 0739 PICT-8046
Fig 0737 PICT-8043a
