HYDRAULIC SYSTEM
6-3TX525 Service Manual Rev. 000
8. Using a 13/16” wrench, disconnect the hydraulic line
marked E from the 2 spool loader valve (Fig. 0839).
Fig 0839 PICT-4880a
9. Using a 13/16” wrench, disconnect the hydraulic line
marked D from the 2 spool loader valve (Fig. 0840).
Fig 0840 PICT-4881a
10. Using a 13/16” wrench, disconnect the hydraulic line
marked C from the 2 spool loader valve (Fig. 0841).
Fig 0841 PICT-4882a
11. Using a 13/16” wrench, disconnect the hydraulic line
marked B from the 2 spool loader valve (Fig. 0842).
Fig 0842 PICT-4884a
