HYDRAULIC SYSTEM
6-59TX525 Service Manual Rev. 000
8. Using a magnet, remove the large ball from the
spring retainer (Fig. 1052).
10. Remove the spring retainer block from the valve
(Fig. 1054).
Fig 1052 PICT-2684a
Fig 1054 PICT-2686a
11. Using a 13mm wrench, loosen the spring retainer
from the valve (Fig. 1055).
9. Remove the spring from inside the spring retainer
(Fig. 1053).
Fig 1055 PICT-2687a
Fig 1053 PICT-2685a
