HYDRAULIC SYSTEM
6-67TX525 Service Manual Rev. 000
10. Place a small amount of grease to the center open-
ing of the spring retainer (Fig. 1084).
12. Place the steel collar over a punch with the shoulder
of the collar downward (Fig. 1086).
Fig 1084 PICT-2730a
Fig 1086 PICT-2726a
13. Install the steel ball into the center retainer opening
and onto the spring (Fig. 1087).
11. Place a small amount of grease at each of the outer
openings of the spring retainer (Fig. 1085).
Fig 1087 PICT-2733a
Fig 1085 PICT-2731a
