Xerox PHASER 6250 Service Manual

3-32 Phaser 6250 Color Laser Printer Service Manual
16
Perform Steps 1 through 3 on page 8-19.
Open and close the front door.
Observe the Turn Roller.
Does the Turn Roller turn while the
machine is warming up?
Go to Step 19. Go to Step 17.
17
Using service diagnostics, test the Tray 1
Turn Clutch.
Does the Turn Clutch Assembly function
normally?
In the test, actuate the Interlock switch.
Check the Clutch
for slip or the gear
for damage.
Replace if
necessary.
Go to Step 18.
18
Remove the clutch connector J19.
Check the following pins;
Is J19-1 <=> J19-2 less than 200Ω?
Replace the
Engine Control
Board, page 8-107.
Replace the
MPT Turn
Clutch,
page 8-34.
19
Does the Feed Gear in Tray 1 turn when
printing 1 sheet of paper?
Check parts for
damage or
obstructions in the
paper path.
Go to Step 20.
20
Use service diagnostics to test the Tray 1
Feed Solenoid.
Does the solenoid actuate?
In the test, actuate the Interlock Switch.
Check the spring
and stopper of the
Feed Solenoid.
Go to Step 21.
21
Remove the Tray 1 Feed Solenoid
connector J132;
Is J132-1 <=> J132-2 less than 100Ω?
Go to Step 22. Replace the Tray
1 Feed Solenoid.
22
Check the Front 2 Harness for continuity. Replace the
Engine Control
Board, page 8-107.
Replace Front 2
Harness
Assembly, PL
6.1.2.
Troubleshooting Procedure Table (Continued)
Steps Actions and Questions Yes No
