YASKAWA V1000 Series Installation & Start-Up Manual

4.4 Basic Parameter Adjustments
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 127
Start-Up Programming & Operation
4
■ Carrier Frequency Selection (C6-02)
Fixed Carrier Frequencies
The carrier frequency can be set using parameter C6-02 as shown in table below.
Use the following guideline to set up the carrier frequency:
Parameter Name Description Setting Range Default
C6-02
Carrier
frequency
1: 2.0 kHz
2: 5.0 kHz
3: 8.0 kHz
4: 10.0 kHz
5: 12.5 kHz
6: 15.0 kHz
7: Swing PWM1
8: Swing PWM2
9: Swing PWM3
A: Swing PWM4
F: User defined (C6-03 to C6-05)
1 to F
depends on
drive size
TERMS
TERMS
TERMS
Swing PWM uses low carrier frequency but by applying special PWM patterns
the audible noise of the motor is kept low.
Symptom Remedy
Speed and torque are unstable at low speeds.
Lower the carrier frequency.
Noise from the drive is affecting peripheral devices.
Excessive leakage current from the drive.
Wiring between the drive and motor is too long.
<1>
<1> The carrier frequency may need to be lowered if the motor cable is too long. Refer to the table
below.
Motor acoustic noise is too loud. Increase the carrier frequency or use Swing PWM.
Wiring Distance Up to 50 m Up to 100 m Greater than 100 m
C6-02 (Carrier Frequency
Selection)
0 to 6 (15 kHz) 0 to 4 (10 kHz) 0 to 2 (5 kHz)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
