YASKAWA V1000 Series Installation & Start-Up Manual

4.4 Basic Parameter Adjustments
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 149
Start-Up Programming & Operation
4
E2-09 Motor Mechanical Loss
Displayed only when using Open Loop Vector Control. It is not
necessary to set this parameter, but it may require adjustment
under the following circumstances:
Large amount of torque loss relative to motor bearings
Fan and pump type applications that have a large amount of
torque loss
The amount of mechanical loss will be reflected in the amount of
torque compensation.
359
E2-10
Motor Iron Loss for
Torque Compensation
Displayed only when using V/f Control. Increase the motor iron
loss in watts in order to increase the accuracy of torque
compensation.
359
E2-11 Motor Rated Output
Sets the motor rated power in kilowatts (kW). This value is
automatically set during Auto-Tuning in units of 0.01
(1HP = 0.746 kW).
359
E2-12
<1>
Motor Iron-Core
Saturation Coefficient 3
Set to the motor iron saturation coefficient at 130% of magnetic
flux. This value is automatically set during rotational
Auto-Tuning.
360
<1> Parameters E2-07 through E2-08 and E2-12 may be difficult to set manually. If Auto-Tuning is not
possible, simply leave these settings at the default values.
No. Parameter Name Setting Method Page

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
