YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 359
Parameter List
B
E2-02
Motor Rated
Slip
Sets the motor rated slip in hertz (Hz). This
value is automatically set during rotational
Auto-Tuning.
0.00 to
20.00
<12> AA− 30F —
E2-03
Motor
No-Load
Current
Sets the magnetizing current of the motor as a
percentage of full load amps (E2-01). This
value is automatically set during rotational
Auto-Tuning.
0 to less
than
E2-01
<12> AA− 310 —
E2-04
Number of
Motor Poles
Sets the number of motor poles. This value is
automatically set during Auto-Tuning.
2 to 48 4 poles A A − 311 —
E2-05
Motor
Line-to-Line
Resistance
Sets the phase-to-phase motor resistance in
ohms. This value is automatically set by
Auto-Tuning.
0.000 to
65.000
<37>
<12> AA− 312 —
E2-06
Motor
Leakage
Inductance
Sets the voltage drop due to motor leakage
inductance as a percentage of motor rated
voltage. This value is automatically set during
Auto-Tuning.
0.0 to
40.0
<12> AA− 313 —
E2-07
Motor
Iron-Core
Saturation
Coefficient 1
Sets the motor iron saturation coefficient at
50% of magnetic flux. This value is
automatically set during rotational
Auto-Tuning.
0.00 to
0.50
0.50 − A − 314 —
E2-08
Motor
Iron-Core
Saturation
Coefficient 2
Sets the motor iron saturation coefficient at
75% of magnetic flux. This value is
automatically set during rotational
Auto-Tuning.
[E2-07]
to 0.75
0.75 − A − 315 —
E2-09
Motor
Mechanical
Loss
Sets the motor mechanical loss as a
percentage of motor rated power (kW)
capacity. This parameter does not typically
require adjustment. Adjust in the following
circumstances:
When there is a large amount of torque loss
due to motor bearing friction.
When there is a large amount of torque loss.
0.0 to
10.0
0.0% − A − 316 —
E2-10
Motor Iron
Loss for
Torque
Compensation
Sets the motor iron loss in watts (W).
0 to
65535
<12> A −− 317 —
E2-11
Motor Rated
Output
Sets the motor rated power in kilowatts (kW).
This value is automatically set during
Auto-Tuning in units of 0.01
(1HP = 0.746 kW).
0.00 to
650.00
0.40
kW
<12>
SS− 318 147
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
L
V
P
M
