A.3 Common Drive Specifications
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 319
Specifications
A
Design Features
Harmonics Countermeasures
DC Bus/Link Choke Option
AC Line Reactor Option
Input Noise Filter
IEC61800 C2 and C3 filters are “bottom
mounted” factory installed
(User installation also available)
Energy Savings Feature ~ Yes (no tuning required in V/f Control)
Diagnostics
Viewable Monitors Monitors: Quantity 45
Fault Storage
Last 10 Faults with elapsed time
Most Recent Fault stored with 15 trace data
points such as output frequency, output
voltage, frequency reference
DIN Rail Mountable ~
Zero side clearance allowed with derating.
Equal height dimensions for:
Single-Phase models BA0001 to BA0020
Three-Phase models 2A0001 to 2A0020
Three-Phase models 4A0001 to 4A0011
Wire Access Bottom entry for wiring
Elapsed Timer ~ Yes (Power-up or Run Time)
Parameter Initialization ~
Factory and user-specific parameter
initialization
Keypad Design
Display 6 LED indicators
Key Quantity 8
Motor Operated Pot.
UP/Down Control
~Yes
Parameter Upload/Download PC Software Drive Wizard via converter (option)
Drive Function
Customization
~
DriveWorksEZ (DWEZ), DWEZ Pro version
(option)
Flash Writable/Upgradeable Yes
Preset Speeds Quantity 17-steps (including jog)
Reverse Prohibit ~Yes
Drive Enable Run Permissive ~Yes
Speed Search/Synchronized
Start Function
Detection Method Speed Estimation-Type Speed Search
Bi/Uni- Directional Bi-directional for Speed Detection Method
Time Delay On/Off Function ~ On/Off Delay (0-3000.0 s)
V/f Patterns ~ 15 Preset, 1 Custom
Torque Boost ~
Manual and Automatic w/adjustable gain,
limit and time
Torq u e L imit
Open Loop Vector Control only. Parameters
offer control settings in four quadrants.
Item Specification
