YASKAWA V1000 Series Installation & Start-Up Manual

A.3 Common Drive Specifications
320 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Maintenance
Maintenance
Component life monitor
Forecasts performance life for electrolytic
capacitors, fan, IGBTs, control relays.
Reminder alarm Yes
Parts Replacement
Fan
(control board, front cover, terminal board)
Parameter Back-up
Yes
(storage on removable I/O terminal board)
Replacement Assistance Yes, Drive Replacer software
Inputs and Outputs
Inputs-Analog
Quantity 2
Signal Level Type
Voltage Input:
DC 0~+10 V (20 kOhms)
Resolution: 1/ 1000 (10 bit)
Current Input:
4-20 mA (250 Ohms) or
0-20 mA (250 Ohms)
Resolution: 1/ 500 (9 bit)
Resolution
+10 VDC: Resolution: 1/ 1000 (10 bit)
4-20 mA: Resolution: 1/ 500 (9 bit)
Scan Rate 2 ms
Loss Detection Yes
Bias and Gain Adjustments Yes
Programmable Functions Yes
Inputs-Digital
Quantity 7 (optically isolated, programmable)
Signal Level Type
24 VDC sourcing or sinking PNP/NPN photo
coupler isolation 8 mA
Scan Rate 4 ms
Programmable Functions Yes
Inputs-Digital Pulse Train
Quantity 1
Input Frequency Range 0-33 kHz
Signal Level
Low Level: 0.0 to 0.8 Vdc
High Level: 3.5 to 13.2 Vdc
Duty Cycle: 30 to 70%
3 kOhm Impedance
Bias and Gain Adjustments Yes
Programmable Functions Yes
Outputs-Analog
Quantity 1
Signal Level Type 0-10V (2 mA or less)
Bias and Gain Adjustments Yes
Scan Rate 2 ms
Programmable Functions Yes
Item Specification

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
